Voltronic Axpert King II 5Kw 48V 5000-48 Off Grid Island Solar Inverter
€729,30 (Tax Excl. .€663,00)
- Description
- Additional information
Description
Voltronic Axpert King II 5Kw 48V 5000-48 Off Grid Island Solar Inverter
• Alternating Current Power 5kw
• Support for 48V battery packs with 100A charge controller
• Installable power 6kw panels
• Zero transfer time (0 ms) to protect critical loads such as servers and ATMs
• Removable LCD control module with multiple communications
• Integrated Wifi for mobile monitoring
• Supports USB On-the-Go function
• Communication port reserved for BMS (RS485)
• Pure sine wave solar inverter
• High power selectable charging current
• Wide range of DC inputs
• Compatible with mains voltage or generator power supply
• Automatic restart during CA recovery.
• Overload and short circuit protection
• Smart charger design for optimized battery performance
• Cold start function
• Optional parallel operation up to 9 units
• Direct BMS support of Pylontech US2000, Solarpower24, Yilink and other batteries
Table 1 Line Mode Specifications
|
INVERTER MODEL
|
5KW
|
6KW
|
|
Input voltage waveform
|
Sinusoidal |
|
|
Rated input voltage
|
230Vac |
|
|
Low voltage loss
|
110Vac ± 7V |
|
|
Low Return Voltage Drop
|
120Vac ± 7V |
|
|
High Voltage Drop
|
280Vac ± 7V |
|
|
High Return Voltage Drop
|
270Vac ± 7V |
|
|
Max. AC input voltage
|
300Vac |
|
|
Rated input frequency
|
50Hz / 60Hz (Auto Detect) |
|
|
Low Frequency Drop
|
46 (56) ± 1Hz |
|
|
Low Return Voltage Drop
|
46.5 (57) ± 1Hz |
|
|
High Frequency Drop
|
54 (64) ± 1Hz
|
|
|
High Return Voltage Drop
|
53 (63) ± 1Hz |
|
|
Power factor
|
>0,98 |
|
|
Short circuit protection at the output
|
Line Mode: Differential Battery mode: Electronic Circuits |
|
|
Efficiency (Line Mode)
|
93% (peak efficiency) |
|
|
Transfer duration
|
Line mode ßà Battery mode 0ms Inverter ßà Bypass 4ms |
|
Table 2 Battery Mode Specifications
|
INVERTER MODEL
|
5KW
|
6KW
|
|
Rated output power
|
5KVA / 5KW |
6KV / 6KW |
|
Output voltage waveform
|
Pure sine wave |
|
|
Output voltage regulation
|
230Vac ± 5% |
|
|
Output frequency
|
50Hz or 60Hz |
|
|
Peak efficiency
|
92% |
|
|
Overload protection
|
5s @ ≥150% load; 10s @ 110 %~150% load; 100ms @ ≥200% load |
|
|
Overload capacity
|
2 * Rated power for 5 seconds |
|
|
Nominal DC input voltage
|
48Vdc |
|
|
Exercise interval
|
40Vdc -66Vdc |
|
|
Cold start voltage
|
46Vdc |
|
|
Low DC alarm voltage
|
45.0Vdc 44.0Vdc |
|
|
@ load< 50% |
||
|
@ load ≥ 50% |
||
|
Low DC Alarm Return Voltage
|
47.0Vdc 46.0Vdc |
|
|
@ load< 50% |
||
|
@ load ≥ 50% |
||
|
Low DC cutoff voltage
|
43.0Vdc 42.0Vdc |
|
|
@ load< 50% |
||
|
@ load ≥ 50% |
||
|
High recovery DC voltage
|
64Vdc |
|
|
High DC cutoff voltage
|
66Vdc |
|
|
Consumption without load
|
<75W |
|
Table 3 Charge Mode Specifications
|
Charge mode |
|||
|
INVERTER MODEL
|
5KW
|
6KW
|
|
|
Charging current
@ Nominal input voltage
|
Default: 30A, max: 100A. |
Default: 60A, max: 120A |
|
|
Bulk Charge Voltage
|
Lead-acid battery
|
58.4Vdc |
|
|
AGM / Gel battery
|
56.4Vdc |
||
|
Charging float voltage
|
54Vdc |
||
|
Overload protection
|
66Vdc |
||
|
Charging algorithm
|
3 step |
||
|
Charge curve
|
|
||
Table 4 Solar Specifications
|
INVERTER MODEL
|
5KW
|
6KW
|
|
Nominal power
|
6000W |
7000W |
|
Max. PV array open circuit voltage
|
500Vdc |
|
|
PV array MPPT voltage range
|
120 ~ 430V |
|
|
Maximum solar input current
|
27A |
|
Table 4 Bypass Mode / ECO Mode Specifications
|
Bypass mode |
||
|
INVERTER MODEL
|
5KW
|
6KW
|
|
Input voltage waveform
|
Sinusoidal |
|
|
Low voltage loss
|
176Vac ± 7V |
|
|
Low Return Voltage Drop
|
186Vac ± 7V |
|
|
High voltage loss
|
280Vac ± 7V |
|
|
High Return Voltage Drop
|
270Vac ± 7V |
|
|
Rated input frequency
|
50Hz / 60Hz (Auto Detect) |
|
|
Low Frequency Drop
|
46 (56) ± 1Hz |
|
|
Low Return Voltage Drop
|
46.5 (57) ± 1Hz |
|
|
High Frequency Drop
|
54 (64) ± 1Hz
|
|
|
High Return Voltage Drop
|
53 (63) ± 1Hz |
|
Table 5 General Specifications
|
INVERTER MODEL
|
5KW
|
6KW
|
|
SCC type
|
MPPT
|
|
|
Possible Parallel
|
YES |
|
|
Communication
|
RS232 and Wi-Fi |
|
|
Safety Certification
|
THERE IS |
|
|
Operating temperature range
|
– 10 ° C + 50 ° C |
|
|
Storage temperature
|
-15 ° C ~ 60 ° C |
|
|
Humidity
|
5 – 95% relative humidity (non-condensing) |
|
|
Dimensions
(P * L * H), mm
|
140 x 295 x 468 |
|
|
Net weight, kg
|
12 |
|
.
The product can be sold with VAT reduced to 10% exclusively to Italian residents with shipping to Italy. In case of foreign customers, please visit the Inverter for EU countries section of the website
THE FORM YOU CAN FIND HERE
https://www.cercastock.it/repository/_barba_srl_dich_10.pdf
THE PRODUCT CANNOT BE SHIPPED UNTIL THE COMPLETED FORM IS RECEIVED
TO THE EMAIL ADDRESS ebay.barbasrl@gmail.com or by fax to 0545030125
Additional information
| Weight | 15 kg |
|---|
