DC Thermal Magnet Direct Current FEEO FPV-63 4 Poles 16A Up to 1000VDC
€34,10 (Tax Excl. .€31,00)
- Description
Description
DC Thermal Magnet Direct Current FEO FPV 63 2P IN E 2P OUT (4 Poles) 16A 1000VDC
THE PRODUCT CAN BE USED AS:
A) 2 POLES IN AND 2 POLES OUT 16A 1000VDC
B) 4 POLES IN AND 4 POLES OUT 16A 550 VDC
FPV-63 4P DC MCB apply to rating current 63A or less, It is mainly used for the overloading and short circuit protection in DC distribution system equipment and electric equipment. It can be widely used in electric, post, traffic, mining enterprise and different kinds of fields.
|
FPV-63 Series Circuit Breaker |
FPV-63 |
|
|
Frame Degree Rated Current (A) |
63 |
|
|
Pole |
1P, 2P, 3P, 4P |
|
|
Rated Operating Voltage (VDC) |
DC12V-DC1200V |
|
|
Rated Current In (A) |
1-63A |
|
|
Rated Insulation Voltage Ui (VDC) |
1200VDC |
|
|
Rated Impact Voltage Uimp (KV) |
4 |
|
|
Ultimate Breaking Capacity Icu (KA) |
6 |
|
|
Run Breaking Capacity Ics (% Icu) |
75% |
|
|
Curve Type |
C. |
|
|
Trip Type |
Thermal-magnetic |
|
|
Mechanical |
Actual average value |
20000 |
|
Standard |
8500 |
|
|
Electric |
Actual average value |
2500 |
|
|
|
|
|
Standard |
1500 |
|
