Sale
SolarPower24 WALL LIFEPO4 Battery 100ah 48 volts 4.8kw
€880,00
Offer Ends In:
14Days09Hours53Minutes53Seconds
| MODEL | BT-SP-WLF48V100AH |
| ELECTRICAL FEATURES | |
| Nominal Capacity (10 h) | 100ah |
| Nominal voltage | 48V |
| Power | 4800W |
| Internal Resistance | <= 80mΩ |
| Charge / Discharge cycles with 100% DOD | >2500 |
| Charge / Discharge cycles with 80% DOD | >5000 |
| DIMENSIONS, WEIGHT, CONNECTOR | |
| Width mm | 442 |
| Depth mm | 400 |
| Height mm | 220 |
| Approximate Weight Kg | 60 |
| CHARGE AND DISCHARGE VALUES | |
| Bulk Charge Voltage | 53.00-53.75v |
| Float Charge Voltage | 51.00-52.00v |
| Charge Current | 25A |
| Maximum Charge Current | 50A |
| Maximum discharge current | 100A |
| OPERATING TEMPERATURES | |
| Load | 0-45 ° C |
| Download | -20-60 ° C |
| Storage | 0-40 ° C |
| COMMUNICATION INTERFACES | |
| Modbus | |
| RS485 / RS232 | |
| Product specifications can be changed without notice | |
| For the complete data sheet click click here | |
- Description
- Additional information
- Download Documents
- Reviews (0)
Description
- Applications:
- Photovoltaic systems compatible with any inverter that supports 48v lead batteries
- Wind farms
- Boating Boats Camper Caravan
- Golf / Electric Trolleys
Main features:
- Convenient wall mounting
- Photovoltaic systems compatible with any inverter that supports 48v lead-acid batteries as it is equipped with its own BMS for the management of over / under voltage and over / under charge protection
- 100ah 48v for an effective capacity of 4.80kw
- after 6000 cycles of use still a residual capacity of 80%
- possibility of parallel installation up to 40 units for a total storage capacity of 192kw
| MODEL | BT-SP-WLF48V100AH |
| ELECTRICAL FEATURES | |
| Nominal Capacity (10 h) | 100ah |
| Nominal Voltage | 48V |
| Energy | 4800W |
| Internal Resistance | <=80mΩ |
| Charge/discharge cycles with 100% DOD | >2500 |
| Charge/discharge cycles with 80% DOD | >5000 |
| DIMENSIONS, WEIGHT, CONNECTOR | |
| Width mm | 442 |
| Depth mm | 400 |
| Height mm | 220 |
| Approximate Weight Kg | 60 |
| CHARGE AND DISCHARGE VALUES | |
| Bulk Charging Voltage | 52.50v |
| Float Charging Voltage | 52.5v |
| Charging Current | 25A |
| Maximum Charging Current | 50A |
| Maximum discharge current | 100A |
| OPERATING TEMPERATURES | |
| Charge | 0-45° C |
| Download | -20-60° C |
| Storage | 0-40° C |
| COMMUNICATION INTERFACES | |
| Modbus | |
| RS485 / RS232 | |
| Product specifications can be changed without notice | |
Download Documents
SP24 Wall LifePO4 48 Volt 100ah/150ah Battery Kit
